Replication Internals: Decoding the MySQL Binary Log Part 10: ROTATE_EVENT — Closing the File and Pointing at the Next One

In this tenth post of our series, we decode the ROTATE_EVENT — the event that closes a binary log file and tells every reader, replica or local, where to look next.

---

Introduction

The ROTATE_EVENT (event type 4, 0x04) is the bookmark MySQL leaves at the end of a binary log file. It carries two pieces of information:

• The name of the binary log file to read next.
• The starting position within that next file (always 4, the byte right after the 4-byte magic number from Part 2).

Together those two fields are enough for any reader — a replica's I/O thread, a mysqlbinlog invocation, a CDC tool — to seamlessly continue from one file into the next. ROTATE_EVENT also has a second life on the wire: when a replica connects, the source sends an artificial ROTATE_EVENT first to tell the replica which file the upcoming events belong to. We'll see how to tell the two apart.

For our binlog.000024, the ROTATE_EVENT is the last event in the file — every byte before it has now been decoded across Parts 2–9.

---

Event Location

Position  1397: XID_EVENT (31 bytes)            ← Last DML transaction commits
Position  1428: ROTATE_EVENT (44 bytes)         ← End of file → binlog.000025
Position  1472: (end of file)

---

Reading the Raw Bytes

$ xxd -s 1428 -l 44 binlog.000024
00000594: 3910 3568 0401 0000 002c 0000 00c0 0500  9.5h.....,......
000005a4: 0000 0004 0000 0000 0000 0062 696e 6c6f  ...........binlo
000005b4: 672e 3030 3030 3235 de7e 7110            g.000025.~q.

The event is 44 bytes: 19-byte common header + 8-byte post-header + 13-byte body (the filename) + 4-byte checksum.

---

Common Header (19 bytes)

39103568 04 01000000 2c000000 c0050000 0000
│        │  │        │        │        │
│        │  │        │        │        └─→ Flags: 0x0000
│        │  │        │        └───────────→ Next Position: 1472
│        │  │        └────────────────────→ Event Size: 44 bytes
│        │  └─────────────────────────────→ Server ID: 1
│        └────────────────────────────────→ Event Type: 4 (ROTATE_EVENT)
└─────────────────────────────────────────→ Timestamp: 1748308025

Field	Bytes	Little-Endian	Value
Timestamp	39103568	0x68351039	1748308025 (2025-05-27 01:07:05)
Event Type	04	0x04	4 (ROTATE_EVENT)
Server ID	01000000	0x00000001	1
Event Size	2c000000	0x0000002c	44 bytes
Next Position	c0050000	0x000005c0	1472
Flags	0000	0x0000	No flags

Cross-check: 1428 + 44 = 1472, and the file is exactly 1472 bytes long. ✓

The flags field is 0x0000. In particular, LOG_EVENT_ARTIFICIAL_F (bit 0x0020, defined in sql/log_event.h:277) is not set — this is a real on-disk ROTATE_EVENT, written by the server when it closed binlog.000024. We'll come back to artificial ROTATE_EVENTs in a moment.

---

ROTATE_EVENT Structure

The layout is documented in the `Rotate_event` class:

Field	Size	Description
Post-Header (8 bytes)	ROTATE_HEADER_LEN
pos	8 bytes	Byte position at which the first event begins in the next file (little-endian uint64)
Body
new_log_ident	Variable	Name of the next binary log file — no null terminator, length runs to the end of the event

The body is intentionally not null-terminated. The reader computes its length from the bytes still available after the post-header, minus the trailing 4-byte checksum. From Rotate_event::Rotate_event() in libs/mysql/binlog/event/control_events.cpp:

if (post_header_len) {
  READER_ASSERT_POSITION(header_size + R_POS_OFFSET);
  READER_TRY_SET(pos, read<uint64_t>);
  ...
} else
  pos = 4;

ident_len = READER_CALL(available_to_read);
if (ident_len == 0) READER_THROW("Event is smaller than expected");

if (ident_len > FN_REFLEN - 1) ident_len = FN_REFLEN - 1;

READER_TRY_SET(new_log_ident, strndup<const char *>, ident_len);

Two things worth noting:

• The fallback pos = 4 exists for legacy binary logs from MySQL versions where ROTATE_EVENT had no post-header. In binlog format version 4 (every modern MySQL), the post-header is always 8 bytes and pos is read from it. The default value 4 is also what we expect to see: it's LOG_EVENT_OFFSET, the byte right after the 4-byte magic number where the first event of any binary log lives.
• The filename is capped at FN_REFLEN - 1 (511) bytes, but in practice it's tens of bytes — basenames like binlog.000025.

The write side (Rotate_log_event::write() in sql/log_event.cc) mirrors the layout exactly:

bool Rotate_log_event::write(Basic_ostream *ostream) {
  char buf[Binary_log_event::ROTATE_HEADER_LEN];
  int8store(buf + R_POS_OFFSET, pos);
  return (
      write_header(ostream, Binary_log_event::ROTATE_HEADER_LEN + ident_len) ||
      wrapper_my_b_safe_write(ostream, (uchar *)buf,
                              Binary_log_event::ROTATE_HEADER_LEN) ||
      wrapper_my_b_safe_write(ostream,
                              pointer_cast<const uchar *>(new_log_ident),
                              (uint)ident_len) ||
      write_footer(ostream));
}

int8store is MySQL's 8-byte little-endian integer store (the same primitive we've been seeing since Part 1), then the filename is appended as raw bytes.

---

Field-by-Field Decoding

Post-Header — pos: 0400000000000000

04 00 00 00 00 00 00 00 → little-endian uint64 → 0x0000000000000004 = 4

The first event in the next binary log starts at byte 4, immediately after the 4-byte magic number. As we saw above, this is LOG_EVENT_OFFSET and it's the value used for every "normal" rotation. (This field exists at all because the same ROTATE_EVENT structure is used when a replica's I/O thread has been told to start reading from a non-default offset — but that's a special case the server-side rotation never produces.)

Body — new_log_ident: 13 bytes

62 69 6e 6c 6f 67 2e 30 30 30 30 32 35
b  i  n  l  o  g  .  0  0  0  0  2  5

The next binary log is binlog.000025. The string runs from the start of the body to the byte before the 4-byte checksum — there is no null terminator and no length prefix.

Checksum: de7e7110

de 7e 71 10 → CRC32 of the entire event

---

Visual Breakdown

Position 1428: ROTATE_EVENT (44 bytes)

┌─────────────────────────────────────────────────────────────────────────┐
│                         COMMON HEADER (19 bytes)                        │
├─────────────────────────────────────────────────────────────────────────┤
│ 39103568     │ 04   │ 01000000 │ 2c000000 │ c0050000 │ 0000            │
│ Timestamp    │ Type │ ServerID │ Size     │ NextPos  │ Flags           │
│ 1748308025   │ 4    │ 1        │ 44       │ 1472     │ 0x0000          │
└─────────────────────────────────────────────────────────────────────────┘

┌─────────────────────────────────────────────────────────────────────────┐
│                         POST-HEADER (8 bytes)                           │
├──────────────────────────────┬──────────────────────────────────────────┤
│ 0400000000000000             │ pos: 4 (start of first event in next file)│
└──────────────────────────────┴──────────────────────────────────────────┘

┌─────────────────────────────────────────────────────────────────────────┐
│                              BODY (13 bytes)                            │
├──────────────────────────────┬──────────────────────────────────────────┤
│ 62696e6c6f672e303030303235   │ new_log_ident: "binlog.000025"           │
│                              │ (no null terminator; length runs to CRC) │
└──────────────────────────────┴──────────────────────────────────────────┘

┌─────────────────────────────────────────────────────────────────────────┐
│                           CHECKSUM (4 bytes)                            │
├──────────────────────────────┬──────────────────────────────────────────┤
│ de7e7110                     │ CRC32                                    │
└──────────────────────────────┴──────────────────────────────────────────┘

mysqlbinlog output: Rotate to binlog.000025  pos: 4

---

When Is a ROTATE_EVENT Written?

The on-disk ROTATE_EVENT we just decoded is written by MYSQL_BIN_LOG::new_file_impl() — the function the server calls whenever it has decided to close the current binary log file and start a new one. There are several triggers that flow into that single code path:

Trigger	Description
max_binlog_size reached	The current file grew past the configured limit (default 1 GB); the server rotates as soon as the next transaction tries to append.
FLUSH BINARY LOGS / FLUSH LOGS	A user (or a backup tool) explicitly requested a rotation.
Server startup	Each restart begins a new binary log file, so the previous file gets a closing ROTATE_EVENT pointing at the new one.
RESET BINARY LOGS AND GTIDS	Wipes existing logs and starts fresh; the residual rotate marker preserves the file linkage during the reset.

All four paths produce the same on-disk shape: post-header pos = 4, body = the next file's basename, no special flags. The construction at the call site looks like this:

Rotate_log_event r(new_name + dirname_length(new_name), 0, LOG_EVENT_OFFSET,
                   is_relay_log ? Rotate_log_event::RELAY_LOG : 0);

LOG_EVENT_OFFSET is 4, and dirname_length(new_name) strips the directory so only the basename ends up in the body. The RELAY_LOG flag is a runtime-only bit on the in-memory class (used to tag relay-log rotations on the replica side); it is not written into the on-disk flags field, which is why our event shows 0x0000 even though it lives in a binlog (rather than relay log).

---

Two Kinds of ROTATE_EVENT

ROTATE_EVENT also shows up on the network protocol between source and replica, in two different forms. Telling them apart is mostly a matter of looking at the common header.

Real (on-disk) ROTATE_EVENT — the one we just decoded:

• Written by the source as the last event of a binary log file when it closes that file.
• Has a real timestamp (the rotation time).
• Flags = 0x0000 (no LOG_EVENT_ARTIFICIAL_F).
• The next_position field in the common header points past the end of the current file.
• Persisted to disk; it stays in the file forever.

Artificial ROTATE_EVENT — the very first event a replica's I/O thread receives when it (re)connects to a source. It exists so the replica knows which file the upcoming events belong to, before it has seen any FORMAT_DESCRIPTION_EVENT for that file:

• Generated on the fly in memory by the source's dump thread; never written to disk.
• Timestamp = 0 (epoch) — this is a tell-tale sign you're looking at an artificial event.
• Flag LOG_EVENT_ARTIFICIAL_F (0x0020) is set in the common header.
• The body still carries a filename and a position, but they describe where the dump thread will start streaming from, not a file boundary.

Both shapes parse with exactly the same code; only the surrounding context (and those two flag/timestamp tells) distinguishes them. The class doc on Rotate_event calls this out:

ROTATE_EVENT is generated locally and written to the binary log on the master. It is written to the relay log on the slave when FLUSH LOGS occurs, and when receiving a ROTATE_EVENT from the master. In the latter case, there will be two rotate events in total originating on different servers.

---

Try It Yourself

import struct
from datetime import datetime, timezone

ROTATE_EVENT = 4
LOG_EVENT_ARTIFICIAL_F = 0x0020

with open('binlog.000024', 'rb') as f:
    f.seek(1428)
    header = f.read(19)
    timestamp, event_type, server_id, event_size, next_pos, flags = \
        struct.unpack('<IBIIIH', header)

    assert event_type == ROTATE_EVENT, f"Not a ROTATE_EVENT (got {event_type})"

    # Post-header: 8-byte little-endian position
    pos = struct.unpack('<Q', f.read(8))[0]

    # Body: filename runs up to the 4-byte CRC at the end of the event
    body_len = event_size - 19 - 8 - 4
    new_log_ident = f.read(body_len).decode('ascii')
    crc = f.read(4)

    ts = datetime.fromtimestamp(timestamp, tz=timezone.utc) if timestamp \
         else "(epoch — likely artificial)"

    print(f"ROTATE_EVENT at offset 1428 ({event_size} bytes)")
    print(f"  Timestamp:     {timestamp} ({ts})")
    print(f"  Server ID:     {server_id}")
    print(f"  Next position: {next_pos}")
    print(f"  Flags:         0x{flags:04x}"
          f"{' [ARTIFICIAL]' if flags & LOG_EVENT_ARTIFICIAL_F else ''}")
    print(f"  pos:           {pos}")
    print(f"  new_log_ident: {new_log_ident!r}")
    print(f"  CRC32:         {crc.hex()}")
    print(f"  → Rotate to {new_log_ident}  pos: {pos}")

Output:

ROTATE_EVENT at offset 1428 (44 bytes)
  Timestamp:     1748308025 (2025-05-27 01:07:05+00:00)
  Server ID:     1
  Next position: 1472
  Flags:         0x0000
  pos:           4
  new_log_ident: 'binlog.000025'
  CRC32:         de7e7110
  → Rotate to binlog.000025  pos: 4

Cross-check against mysqlbinlog:

$ mysqlbinlog --no-defaults binlog.000024 | tail -5
# at 1428
#250527  1:07:05 server id 1  end_log_pos 1472 CRC32 0x1071 7ede   Rotate to binlog.000025  pos: 4

Note: The binary log files used in this series (binlog.000024, binlog_gtid_tag.000001, and others) are available at github.com/altmannmarcelo/presentations/tree/main/binlog.

---

References

• Rotate_event — class definition with the binary format documentation
• Rotate_event::Rotate_event() — deserialization constructor (post-header pos, then filename runs to the end of the event)
• Rotate_log_event::write() — serialization (int8store for pos, raw bytes for filename)
• R_POS_OFFSET / R_IDENT_OFFSET — post-header field offsets
• ROTATE_HEADER_LEN = 8 — post-header length constant
• Rotate_event::DUP_NAME / RELAY_LOG — runtime-only flags on the in-memory class (not on-disk)
• MYSQL_BIN_LOG::new_file_impl() — constructs and writes the on-disk ROTATE_EVENT during rotation
• LOG_EVENT_ARTIFICIAL_F — the common-header flag set on artificial ROTATE_EVENTs sent to replicas

---

What's Next?

That's the last event in binlog.000024. Across nine posts (Parts 2 through 10), we've now manually decoded every byte of a real MySQL binary log — from the magic number to the closing ROTATE_EVENT — and seen how each event maps onto MySQL's source code in mysql-9.6.0.

But there's one event we deliberately deferred all the way back in Part 5: the GTID_TAGGED_LOG_EVENT introduced in MySQL 8.4. Tagged GTIDs use a different on-disk encoding from the classic untagged GTID we decoded, and they're worth a post of their own. That's the subject of Part 11.

---

Next up: Part 11: GTID_TAGGED_LOG_EVENT — Tagged GTIDs in MySQL 8.4+

---

This series is based on a presentation given at the MySQL Online Summit. The goal is to help MySQL users understand what goes under the hood of replication by manually decoding binary log files.
